SAMMI DVR: Integral Movil Monitor Advance Sistem
New video digital recording sistem, in real time with perfectly sincronize audio in every channel. Specially made for certification banking area and digital documents researchs. Inteligent sistem which can be use to create tree files of deferent storing . It can also store the ambient recording and the captures caused by alarms |
|
| · Ambient recording: |
Alows the company records video images from all acivities that can be done inside the company ( fifo recording- for 15 days of unstop recording 7/24) |
| · IDcheck recording: |
Allows sequence capture from 3 cameras inside, how shows the client id, client picture, check cliente and finger print more than 2.000.000 images storage |
| · Captures by alarms: |
allows the captures of images taken in the moment that alarm sing is produced. It make easier the search of those kind of incidents, allowing the operator to search the incident in no time. |
| · Remote automatic conexión: |
This new sistem allows to conect automaticly to maestro control center by lan/wan/internet in the moment that an alarm sing is produced. |
| · Real time: |
(frames per second) per channel, giving 16 channels (perfectly sincronize). |
| · Real time remote transmission: |
It transmit through lan/wan in real time in less than a minute of delay. (video & audio) |
| · Design: |
Case tower design |
| · Recording types: |
Allows recording in diferents ways:
- Normal
- Calendar
- Movement detection
- Capture by alarm |
| · Server Technics Specifications: |
It use the most advance zip algorism extant , video H.264 (mpeg-4/part10) and audio technology oggvorbis several configurations: 4/8/12/16/24/36. Video audio in interface and 8 to 24 alarms in. |
| · Hardware specifications |
- Pentium 4, 2.4 ghz, 512 Mb Ram, HDD 750 Gb. (Can be Expand)
- Video VGA ATI Radeon 9250 128Mb).*
- XP plataform
(*) Monitor not include. |
| · Video: |
- Video way in: 4/8/12/16/24/36 channels in CVBS sign
- Standar: PAL, NTSC
- Brightness Control , Saturation control and hallmark control.
- Resolution:
· 704x288(PAL) - 704x240(NTSC)
· 352x288(PAL) - 352x240(NTSC)
· 176x144(PAL) - 176x120(NTSC)
· 88x72(PAL) - 88x60(NTSC)
- Frames per channel range: 30F/S
- Output range: 32kbps-1000kbps |
| · Audio |
· Audio way in: 4/8/12/16/24/32 audio way in channels.
· Sampling ratio: 16KHz
· Output code ratio: 16kbps |
